- 340nm 의 UV파장을 포함한 최대 8개의 파장 사용 가능
- End Point, Fixed time, Kinetic
- 인큐베이션 시간 및 온도 조절(선택사항) 기능
- 윈도우 XP를 통한 PC 컨트롤 시스템 제공
- 8 채널(8-channel) 광섬유 시스템 적용으로 5초만에 플래이트 측정
- 500개 이상의 프로그램과 100,000개 이상의 결과 저장 기능
- Westguard Multi-Rule 및 Instant method 와 자동 알람 기능을 갖춘 QC관리 프로그램
- ABS, Cut-off, Curve, Linear, Log, Exponential, Power 그리고 4PL regression 을 포함한 계산 모드
- 램프 보호기능과 플래이트 쉐이킹 기능 및 전원 공급 시 자가진단 기능
- 랜덤 포지티브 및 네거티브 컨트롤 세팅
- 한 플래이트에 최대 12개의 서로 다른 분석이 가능한 다중 분석 기능
Technical Specification
Abosrbance Range | 0.000-4.000Abs |
Resloution | 0.001Abs(displayed),0.0001Abs(calculated) |
Wavelengths | 340,405,450,492,630nm,3 more filters optional |
Wavelength Accuracy | ± 1nm |
Band Width | <8nm |
Methodologies | End Point, Fixed time, Kinetic |
Calculation Method | ABS, Cut-Off, Single Standard, Curve, Multi-Percent, Percent Log, Linear, Exponential, Power, 4PL Regression |
Reading Speed | 5 seconds for 96 well plate(Single wavelength) |
Shaking Plate | Shaking time and speed adjustable |
Plate Incubation | Ambient temperature+4~46℃, adjustable |
Optic System | 8-channel optic fiber system |
Light Source | Halogen lamp |
Operation | PC operation, bidirectional communications |
Memory | More than 500 programs, up to 100,000 test results |
Printer | All printers compatible with Windows |
Interface | RS-232 |
Power Requirement | AC 110V-240V ±10%, 50-60 ±1Hz |
Net Weight | 9kg |
Dimensions | LxWxH(mm):186x440x220 |
